1.3 Inch 240x240 UART HMI ESP32 Knob Smart Circular LCD Knob Display with WiFi BLE
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | IPS | Resolution | 240*240 |
| Display Type | TFT | Backlight Type | LED Display Screen |
| Mounting Type | Surface Mount | Brightness | 300Nits |
| Display Size | 1.28 Inch | Supplier Type | China factory directly supply |
| Operating Temperature | --20~70℃ | Screen Size | 1.28 Inch |
| Communication Interface | Uart/USB | Driver Ic | ESP32 C3 |
| Product Name | 1.3 Inch Knob Display | Outline Dimension | 50mm Round |
| Interaction Method | Rotate and Press | Shell Color | Black/Silver/Customized |
| OS | RTOS | CPU | ESP32-C3 160Mhz |
| RAM | 400KB | Flash | 4MB |
| Wireless | 2.4GHz Wi-Fi, BLE 5, BLE Mesh | Platform | Ar-duino ESP-IDF LVGL |
