1.3 Inch Liquid Crystal Display Can Be Opened Mold Customization Highlight Display Screen
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT display screen | Resolution | 240(Horizontal)*240(Vertical) |
| Display Type | IPS | Backlight Type | LED Display Screen |
| Mounting Type | Connector | Brightness | 1000 |
| Display Size | 1.3 inch | Supplier Type | manufacturer |
| Operating Temperature | -20-70 | Screen Size | 1.3 inch |
| Communication Interface | 4line SPI | Driver Ic | ST7789 |
| P/N | C013QH02ES | LCM (W x H x D) (mm) | 26.16*29.13*2.30 |
| Active Area(mm) | 23.40*23.40 | Pixel Pitch | 0.0975*0.0975 |
| Display Mode | Normally black | Viewing | ALL |
| Viewing Direction | 80 | With /Without TP | without TP |
| Contrast | 800 | Storage Temperature | -30-80 |
