1.54 Inch 128x64 Monochrome OLED Display Module SSD1309 Driver Parallel SPI I2C Interface OLED Screen
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | PMOLED | Display Size | 1.54-inch |
| Display Mode | OLED Display | Resolution | 128(H) x 64(V) |
| Outline Dimension(mm) | 42.04 (W) x 27.22(H) | Active Area(mm) | 35.052 (W) x 17.516 (H) |
| Display Drive IC | SSD1309 | Interface | Parallel / 4-wire SPI / I2C |
| Module Connecting Type | Connector (Pitch:0.5mm) | Brightness | 120 (Typ.) |
| Pins | 24 | Color | Monochrome( Yellow/Blue/Blue/White) |
