1.54 Inch 128x64 White Graphic Large OLED Display 154 Oled
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | OLED Display | Display Size | 1.54" |
| Display Mode | PMOLED | Resolution | 128(H) x 64(V) |
| Active Area(mm) | 35.052 (W) x 17.516 (H) | Outline Dimension(mm) | 42.04 (W) x 27.22(H) |
| Display Drive IC | CH1116 | Interface | Parallel / 4-wire SPI / I2C |
| Module Connecting Type | Connector (Pitch:0.5mm, 24PIN | Brightness | White: 100 (Typ.) Blue: 100 (Typ.) Yellow: 130 (Typ.) |
| Pins | 24 | Color | Monochrome( White/Blue/Yellow) |
