1.54'' IPS TFT LCD Display Module 320*320 MIPI Interface with Capacitive Touch Panel for Smart Watch
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT LCD | Resolution | 320x320 |
| Display Type | IPS | Backlight Type | LED Display Screen |
| Mounting Type | Connector | Brightness | 300 |
| Display Size | 1.54 inch | Supplier Type | Manufacturer |
| Operating Temperature | -20--70 | Screen Size | 1.54 |
| Communication Interface | MIPI | Driver Ic | ST7796S |
| Size | 1.54 Inch | Resolution | 320(RGB) * 320 |
| Interface | MIPI | Outline Dimension | 35.7*39.5*2.38 |
| Active Area | 27.72*27.72 | Viewing Direction | All Viewing Direction |
| Display Mode | Normal Bblack | Backlight | White LED(12*LED) |
| Brightness | 300 Cd/m2 |
