1.69 inch 240X280 TFT LCD Display with PCAP Capacitive Touch Screen Panel for Smart Watch
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT+CTP | Display Size | 1.69 |
| Supplier Type | Manufacturer | Display mode | TFT+CTP |
| Resolution | 240(RGB)X280 | Outline Dimension(mm) | 34.2(H) x 41(V) x 3.59Max(D) |
| Active Area(mm) | 27.972(H) x 32.634(V) | TFT Driver IC | ST7789V2 |
| CTP IC | CST816T | Interface | 4-wire SPI |
| Module Connecting Type | Connector | TFT Pins | 16 |
| Brightness | 500cd/m2 |
