1.69 Inch High Resolution 240x280 Capacitive TFT LCD IPS Module with 4-Wire SPI Interface and ST7789 Driver IC 16.7M Colors
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | Capacitive | Communication Interface | 4-Wire SPI |
| Application | display | Interface | SPI |
| Diagonal Screen Size | 1.69 inch | Drive IC | JD9851 |
| Screen Size | 1.69 inch | Size | 1.69 inch |
| Resolution | 240 (H) RGB x280 (V) | Interface Type | 4-Wire SPI |
| Driver IC | ST7789 | Screen Size | 27.972mmx32.664mm |
| Panel Size(mm) | 30.07mmx37.43mmx1.56mm | Active Size(mm) | 27.972mmx32.664mm |
| Color | 262K/16.7M | Storage Temperature | 30~+80C |
