1.9 Inch Tft 170x320 TFT LCD Display Touch Panel Full Viewing Angle with CTP SPI MCU ST7789 CST816D with Customizable Options
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | Capacitive | Communication Interface | 8-bit parallel |
| Mounting Type | Connector | Viewing Angle | Full Viewing Angle |
| Application | SmartWatch | Interface | 4-Wire SPI/8-bit parallel |
| Length | 55.33 | Diagonal Screen Size | 1.9 inch |
| Width | 31.00 | Drive IC | ST7789 |
| Screen Size | 22.7x42.72 | Product Name | 1.9 inch touch screen |
| Driver IC | ST7789 | Touch IC | CST816D |
| Resolution | 170x320 | Pins | 30+6 Pin |
| Panel Size(mm) | 31x55.33x3.64 | Active Size(mm) | 22.7x42.72 |
| Operating Temperature | -20℃~ + 70℃ | Storage Temperature | -30℃~+ 80℃ |
