10.1 Inch High Resolution TFT Capacitive IPS Touch Screen LCD Monitor with 40-Pin 1280*800 HD Display
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | Capacitive | Communication Interface | LVDS |
| Mounting Type | Connector | Application | tablet |
| Interface | I2C | Length | 229.46 |
| Diagonal Screen Size | 10.1 | Width | 149.1 |
| Screen Size | 10.1 | Type | TFT |
| size | 10.1" | Resolution | 1280*800 |
| Module/Panel Size(mm) | 229.46(W) *149.1(H) *2.50(D) mm | Active Area(mm) | 216.96(W) *135.60(H) mm |
| backlight | LED | brightness | 350nits |
| Interface | LVDS | capacitive touch screen | optional |
| Application | Tablet |
