10.1 Inch LCD 1280x800 HD MI Display Capacitive Touch for Industrial HMI Embedded Device Consumer Electronics
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | Capacitive | Communication Interface | HD MI |
| Interface | HD MI | Screen Size | 10.1 inch |
| Panel Size | 10.1 inch | Resolution | 1280 (W) * RGB *800 (H) |
| Active Area | 216.96 (W) * 135.6 (H)mm | Outline Dimension | 229.1(W) * 148.9 (H)mm |
| Touch panel | Capacitive touch panel Via HID-USB | Video Input Interface | HD MI |
| Display Mode | ADS_Normally Black, Transmissive | View Direction | ALL(IPS) |
| Contrast Ratio | 700(Typ.) | Luminance (cd/m^2) | 400 (Typ.) |
