10.1" Normally Black 800*1280 Display LCD 330 Nits 30 Ms GG Capacitive 60% NTSC TFT Touch Panel LCD Custom Display
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT | Resolution | 800*1280 |
| Display Type | TFT | Backlight Type | LED Display Screen |
| Brightness | 330nits | Display Size | 10.1 inch |
| Supplier Type | Manufacturer/Factory | Operating Temperature | -20~60(℃) |
| Screen Size | 162.30*241.10*5.30mm(6.39*9.49*0.21in) | Communication Interface | 33Pin MIPI |
| Driver Ic | JD9365DA-H3 | Display Mode | Normally Black |
| Pixel Arragement | RGB stripe | Contrast Ratio | 1000:1 (Typ.) |
| Active Area(mm) | 135.36*216.58 | Viewing Angle | 80/80/80/80 (Typ.) |
| Storage Temperature | -30~70(℃) | Response Time | 30ms |
| NTSC | 60% | Surface Treatment | AF |
| TP Structure | G+G |
