10 Inch BOE 1280x800 LCD Panel BP101WX1 206 LVDS Cable BOE Technology TFT Lcd Display Screen Lcd Panel
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT | Resolution | 1280X800, WXGA 149PPI |
| Display Type | TFT | Backlight Type | LED Display Screen |
| Mounting Type | Panel Mounting | Brightness | 330 cd/m² (Typ.) |
| Display Size | 10.1 inch | Supplier Type | Agent |
| Operating Temperature | 0 ~ 50 °C(0~90℉) | Screen Size | 10.1" |
| Communication Interface | LVDS (1 ch, 8-bit) , 40 pins Connector | Active Area | 216.96(W)X135.6(H) mm |
| Outline Size | 228.6(W)X149.2(H)X4.59(D) mm | View angle | 80/80/80/80 (Typ.) |
| Contrast ratio | 600:1 | Backlight | WLED , 15K hours , With LED Driver |
| Display mode | ADS, Normally Black, Transmissive | Response | 25 (Typ.)(Tr+Td) ms |
| Color Depth | 16.7M 50% NTSC | Total Consumption | 3.4W (Typ.) |
