12.6 Inch TFT LCD Module NV126B5M-N42 Matching Driver Board Multi Touch Panel EDP 40 Pin for Car Dashboard
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | Capacitive | Communication Interface | I2C |
| Mounting Type | PCB | Viewing Angle | 6 o'clock |
| Application | Car dashboard | Interface | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 40 pins Connector |
| Length | 315.61 mm(12.43in) | Diagonal Screen Size | 12.6 inch |
| Width | 82.9665 mm(3.27in) | Features | Stretched Bar, Ultra Wide, High Quality Display, Match of Driver Board, Match of Touch Panel |
| Drive IC | capasitive | Screen Size | 12.6 inch |
| Touch Points | Multi-Touch | Main Application Field | Diy computer case |
| Operating temperatures | 0 ~ 60 ℃ | Storage temperatures | -20 ~ 65 °C |
| Supply Ability | 2000 pcs/day | Supplier type | OEM/ODM |
| Supply type | in-stock items | Panel Type | a-Si TFT-LCD, LCM |
| Outline Dimension | 315.61(W)x94.02(H) x5.3(D) mm | Color | 16.7M 45% NTSC |
