PRODUCTS
12 Inch HD MI BNC Input LCD Monitor 12" TFT LED VGA CCTV Monitor
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| panel type | TFT | products status | New |
| use | For Business | aspect ratio | 16:10 |
| refresh rate | 60-75Hz | response time | less than 12ms |
| interface type | VGA , Usb, HD, AV, BNC | brightness | 350cd/m |
| contrast ratio | 800:1 | vertical viewing angle | 140° |
| feature | not curved | warranty(year) | 1-Year |
| backlit type | LED | wide color gamut | 99% sRGB |
| horizontal viewing angle | 160° | color | Black |
| screen type | Widescreen | built-in speaker | No |
| series | For Business | private mold | No |
| pixel pitch | 0.285mm(0.01in) | application | Desktop |
| widescreen | Yes | display ratio | 16:10 |
| after-sales service | Call Center and on-line Technical Support, Free Spare Parts, Others | Dot Pitch | 0.285mm(0.01in) |
| Panel Size | 12.1 inch 16:10 | Backlight | LED Backlight |
| OSD language | 8 Languages | Speaker | optional |
| Power Supply | DC 12V 2.0A | Viewing Angle | 160°/140° |
| Refresh rate | 60-75Hz | Power consumption | 10-18W |
| Installation | Desktop or wall mount optional |
