12864 06C COB Graphic LCD Display Module STN Gray LED Backlight 128x64 Dot Matrix 5V 3.3V AIP31107
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | Cob | Resolution | 128*64 |
| Display Type | LCD | Backlight Type | LED Display Screen |
| Mounting Type | Other | Brightness | Highlight |
| Display Size | 75.0X52.6X9.0 MM | Supplier Type | OEM |
| Operating Temperature | -20℃~+70℃ | Screen Size | 75.0X52.6X9.0 MM |
| Communication Interface | 20PIN | Driver Ic | KS0107/AIP31107 |
| Type | 128x64 dot matrix LCM display module | Display Size | Standard or Custom Size |
| DIsplay Mode | STN Gray Positive | Drive Method | 1/64 Duty 1/9 Bias |
| Operating Voltage | 5.0V/3.3V | Viewing Angle | 06:00 |
| Backlight | White LEDs Backlight | Controller IC | KS0107/AIP31107 |
| Module Size | 75.0Wx52.6Hx9.0T MM |
