15.6 Inch EV156FHM-N11 1920x1080 16.7M Color IPS 40pin LVDS LCD Display Screen TFT LCD Panel
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT | Resolution | 1920X1080, FHD 141PPI |
| Display Type | IPS | Backlight Type | LED Display Screen |
| Mounting Type | Panel Mounting | Brightness | 500 cd/m² (Typ.) |
| Display Size | 15.6 inch | Supplier Type | Manufacturer |
| Operating Temperature | 0 ~ 70 °C(0~126℉) | Screen Size | 15.6" |
| Communication Interface | LVDS (2 ch, 8-bit) , 40 pins Connector | View angle | 89/89/89/89 (Typ.) |
| Contrast Ratio | 1200:1 | Backlight Type | WLED , 50K hours, with LED driver |
| Work Mode | ADS , Normally Black , Transmissive | Support Color | 16.7M 78% NTSC |
| Power Consumption | 13.3W | Response Time | 25 (Typ.)(Tr+Td) |
| Weight | 1 KG |
