16x2 STN Square Transparent LCD Display Screen Module with Yellow Green Backlight 3 5V Character Display
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Interface | parallel | Character Format | 6x8 dots |
| Backlight | yellow/green | Type | character lcd display |
| Control Type | st7066 | Mounting Type | PCB |
| Display Size | standard size | Operating Temperature | -30~80 |
| Voltage - Supply | 3~5V | Viewing Area | 180 |
| Character Size | 8*6 | Number of Characters | 16*2 |
| Type | standard,character module | Display type | STN,Y/G,transflective, positive |
| viewing area | 64.3*16.3mm | outline size | 80*36*13.4mm |
| viewing angle | 6:00 | Driving method | 1/16DUTY,1/4BIAS,VLCD=4.5V |
| Dot matrix | 16x2 | working temp | -20~70 |
| storage temp | -30~80 |
