2.0 Inch IPS TFT LCD Display Module with SPI Interface 10Pin 240x320 Resolution White LED Backlight ST7789T3 Driver IC
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT | Resolution | 240x320 |
| Display Type | IPS | Backlight Type | LED Display Screen |
| Mounting Type | PCB | Brightness | TBD |
| Display Size | 2.0 inch | Supplier Type | Manufacturer |
| Operating Temperature | -20°C ~ +70°C | Communication Interface | SPI 4W |
| Driver Ic | ST7789T3 | Outline Dimension | 34.6 (H) x 47.80 (V) |
| Active area | 30.60 (H) x 40.8 (V) | Display color | 262k |
| Viewing Angle | IPS Fulll Angle | Backlight Type | White LED |
| MOQ | 1PCS |
