2.1 Inch 1600*1600 Octagon MIPI Micro TFT LCD Panel 50Pin LCD Screen Module for Micro AR VR Glasses Project LCD Display
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT LCD Display | Resolution | 1600*1600 |
| Display Type | TFT | Backlight Type | LED Display Screen |
| Mounting Type | Board to Board | Brightness | 450cd/m2 |
| Display Size | 2.1 inch | Supplier Type | Manufacturer |
| Operating Temperature | -20+70°C | Screen Size | 2.1 inch |
| Communication Interface | MIPI | Driver Ic | R63455 |
| Interface | MIPI | Viewing Angle | IPS Full Viewing Angle |
| Outline Dimension | 41.2*45.3*1.76mm | Active Area | 38.4*38.4mm |
| Driver IC | R63455 | Luminance | 450cd/m2 |
| FPC Connector | 50 Pin Board to Board Connector | Touch Panel | Without Touch Panel, Support Customization |
| Service | Welcome OEM&ODM |
