PRODUCTS
2.9 Inch LCD Module Display Assembly with Driver IC SSD2116Z PIN54 TN Screen for Industrial Control Display
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT display screen | Resolution | 320(Horizontal)*120(Vertical) |
| Display Type | TFT | Backlight Type | LED Display Screen |
| Mounting Type | Connector | Brightness | 300 |
| Display Size | 2.9 inch | Supplier Type | manufacturer |
| Operating Temperature | -20-70 | Screen Size | 2.9 inch |
| Communication Interface | 18Bit RGB | Driver Ic | SSD2116Z |
| P/N | C029-BT-01 | LCM (W x H x D) (mm) | 76.90*38.22*3.26 |
| Active Area(mm) | 70.56*26.46 | Pixel Pitch | 0.2205*0.2205 |
| Display Mode | Normally White | Viewing | 12 O'Clock |
| Viewing Direction | 65 | With /Without TP | without TP |
| Contrast | 300 | Storage Temperature | -30-80 |
