2 Inch TFT LCD Display Module 240x320 Pixels 20~70 Operating Temp MCU Interface 4 White LED Backlight NV3030A2 Driver IC
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT | Resolution | 240X320 |
| Display Type | TFT | Backlight Type | LED Display Screen |
| Mounting Type | -- | Brightness | 350 |
| Display Size | 2.0 inch | Supplier Type | manufacturer |
| Operating Temperature | -20~70 ℃ | Screen Size | 2.0 |
| Communication Interface | MCU | Driver Ic | NV3030A2 |
| Name | 2.0 inch tft lcd display | Outline Dimension | 35.1*51.2*2.2mm |
| Active Area | 30.6*40.8mm | Resolution | 240*320 |
| Interface | MCU | Driver IC | NV3030A2 |
| Viewing Angle | ALL | Storage temperature | -30~80 ℃ |
| Backlight | 4 White LED |
