2000nits High Brightness 23.8 Inch LCD Module 1920x1080 IPS Wide Temp Sunlight Readable Screen for Outdoor Digital Signage
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT | Resolution | 1920 x1080 |
| Display Type | IPS,Normally Black | Backlight Type | LED Display Screen |
| Mounting Type | Surface Mount | Brightness | 2000 cd/m² (Typ.) |
| Display Size | 23.8inch | Supplier Type | Original Manufacture |
| Operating Temperature | -20℃~+60℃ | Communication Interface | LVDS, 30pins Connector |
| Active Area | 527.04(H)x296.46(V) mm | Outline Dimension | 555.8(H)x325.3(V)x11.7(D) mm |
| Viewing Angle | 89/89/89/89 (Type.) | Contrast Ratio | 1000:1 (Typ.) |
| Backlight Type | 128-chip WLEDs(8S8Px2), 46V/1200mA | Response Time | 20(Typ.)(Tr+Tf) ms |
| Touch Panel | Optional CTP or RTP Touch Screen |
