22 Inch Refurbished LCD Panels 75Hz for Desktop Use and Repairing Monitors
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| panel type | TFT | products status | Used, Refurbished |
| use | For Business | aspect ratio | 16:10 |
| refresh rate | 75Hz | response time | 5 ms |
| interface type | LVDS (2 ch, 8-bit) , 30 pins Connector | brightness | 250cd/m |
| contrast ratio | 1000:1 | vertical viewing angle | 170° |
| feature | not curved | warranty(year) | 90 Days |
| backlit type | LED | wide color gamut | 99% sRGB |
| horizontal viewing angle | 170° | color | Clear |
| screen type | LCD | built-in speaker | No |
| series | For Business | private mold | Yes |
| pixel pitch | 0.282mm(0.01in) | application | Desktop |
| widescreen | Yes | display ratio | 16:10 |
| after-sales service | Call Center and on-line Technical Support | Dot Pitch | 0.282mm(0.01in) |
| Size | 22" | Resolution | 1680*1050 |
| Active Area | 473.76(W)*296.1(H) mm | Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) | Operating Mode | TN, Normally White, Transmissive |
| Support Color | 16.7M 72% NTSC | Light Source | WLED [9S3P] , 30K hours , W/O Driver |
| Power Supply | 5.0V (Typ.) | Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
