23.6" 1280*1280 LCD Panel DV236FBM-N00 Round High Brightness Screen
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT | Resolution | 1280*1280 |
| Display Type | TFT | Backlight Type | LED Display Screen |
| Mounting Type | Panel Mounting | Brightness | 1500 cd/m² (Typ.) |
| Display Size | 23.6 inch | Supplier Type | Original Factory Agent |
| Operating Temperature | 0 ~ 50 °C(0~90℉) | Screen Size | 23.6" |
| Communication Interface | LVDS (2 ch, 8-bit), 30 pins | Active Area | 599.424(W)*599.424(H) mm |
| Outline Dim. | 657(W)*657(H)*28.65(D) mm | Viewing Angle | 89/89/89/89 |
| Contrast ratio | 1000:1 | Backlight | WLED, 50K hrs, With LED Driver |
| Response time | 14m/s | Display mode | ADS, Normally Black, Transmissive |
| Support Color | 16.7M, 72% NTSC | Total Consumption | 90.9W (Typ.) |
