27 Inch 5K Monitor 75Hz Super UHD Resolution 500nits 27 Inch 5120x2880 LVDS IPS LCD Panel Display for Office Display Monitor
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT | Resolution | 5120X2880 |
| Display Type | IPS | Brightness | 500nits |
| Display Size | 27 inch | Supplier Type | Original Manufacture |
| Communication Interface | LVDS | Active Area | 596.736(H)x335.664(V) mm(±0.5) |
| Outline Dimension | 611.2(H)x356.6(V)x13.83(D) mm (±0.5) | Number of Colors | 1.07B (8bits + FRC ) |
| Contrast Ratio | 1700:1 (Typ.) | Backlight | 51.4V/420mA, 21.4W |
| Storage Temperature | -20℃~+60℃ | Operating Temperature | 0℃~+50℃ |
| Response Time | 20(Typ.)(Tr+Tf) ms | Touch panel | Optional Capacitive Touch Panel USB port |
| Driver Board | HD-MI Driver Board Kits |
