3.5 Inch LCD Display Screen 480*640 Transflective IPS Full Viewing for Smart Home Display
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT display screen | Resolution | 480*640 |
| Display Type | IPS | Backlight Type | LED Display Screen |
| Mounting Type | Connector | Brightness | 95 |
| Display Size | 3.5" | Supplier Type | manufacturer |
| Operating Temperature | -20-70 | Screen Size | 3.5 inch |
| Communication Interface | 18Bit RGB+SPI | Driver Ic | HX8363-A |
| P/N | C035VL01NH-P | Pixel Pitch | 0.1116*0.1116 |
| Product Name | TFT Module Screen | Viewing Direction | 80 |
| LCM (W x H x D) (mm) | 64.00*85.00*4.2 | PIN | 40+4 |
| Display mode | Normal Black | Active Area(mm) | 53.57*71.42 |
| Storage Temperature | -30-80 | sunlight readable type | transflective |
