3.5 Inch LCD Module 320x240 QVGA Screen TFT Screen with RGB888 Interface ST7272 Driver IC TFT LCD Display Manufacturer
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT LCD | Resolution | 320x240 |
| Display Type | IPS | Backlight Type | LED Display Screen |
| Mounting Type | Other Mounting Type | Brightness | 350 Cd/m2 (Typ.) |
| Display Size | 3.5 Inch | Supplier Type | Manufacturer |
| Operating Temperature | -20~ 70 °C | Communication Interface | RGB888 |
| Driver Ic | ST7272 | Outline Dimension | 76.9(W)* 63.9(H)*3.1(T) mm |
| Active Area | 70.08(W)* 52.56 (H) mm | Viewing Angle | All viewing Angle |
| Touch panel | Optional Touch Panel |
