3.5 Inch Square IPS Liquid Crystal Display TFT LCD Screen Panel Module Display
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT display screen | Resolution | 320(Horizontal)*480(Vertical) |
| Display Type | IPS | Backlight Type | LED Display Screen |
| Mounting Type | Connector | Brightness | 350 |
| Display Size | 3.5" | Supplier Type | manufacturer |
| Operating Temperature | -20-70 | Screen Size | 3.5 inch |
| Communication Interface | 18bits RGB+SPI | Driver Ic | HX8357D |
| Type | TFT display | Product Name | TFT Module Screen |
| Viewing Angle | IPS | Display mode | Normal Black |
| Viewing Direction | 85 | Contrast | 700 |
| PIN | 45 | LCM (W x H x D) (mm) | 54.66*82.94*2.2 |
| Active Area(mm) | 48.96*73.44 | Storage Temperature | -30-80 |
