3.95 4 Inch Square 480x480 HMI UART LCD Module Capacitive Touch IPS Screen for Industrial Control Systems
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT | Resolution | 480x480 |
| Display Type | IPS Technology Full Viewing Angle | Backlight Type | LED Display Screen |
| Brightness | 350-1000 | Display Size | 4inch |
| Supplier Type | TW04001U | Communication Interface | UART TTL RS485 (3.3V Logic 5V VCC Input) |
| Core Processor | 32-bit RISC Core 200MHz High Speed | Installation Standard | Fits 86 Box (84.2mm x 84.2mm) |
| Storage Space | 128Mbits External Flash | Touch panel | Capacitive Touch Screen (CTP) Integrated |
| Software Ecosystem | Supports UI Editor & LVGL Graphics Library | Graphics Support | LVGL Graphics Library Native Support |
| UI Designer | UI Editor Visual Drag And Drop Tool | System Update | USB Firmware Update |
