4.0 Inch TFT LCD 480*480 Resolution Supports Such As FPC Backlight Cover Plate Smart Device Displays
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT display screen | Resolution | 480(Horizontal)*480(Vertical) |
| Display Type | IPS | Backlight Type | LED Display Screen |
| Mounting Type | Connector | Brightness | 290 |
| Display Size | 4.0" | Supplier Type | manufacturer |
| Operating Temperature | -20-70 | Screen Size | 4.0 inch |
| Communication Interface | RGB+SPI | Driver Ic | ST7701S |
| P/N | C040WQB01NS-DF | Pixel Pitch | 0.1462*0.1497 |
| Display Mode | Normally Black | Viewing | ALL |
| Viewing Direction | 80 | PIN | 50 |
| LCM (W x H x D) (mm) | 83.70*83.70*2.83 | Active Area(mm) | 71.86*70.18 |
| With /Without TP | CTP | Storage Temperature | -30-80 |
