4.3 Inch Touch Screen 480x272 40PIN IPS TFT LCD Display Module RGB Interface Resistive Touch 500cd/m Brightness 262K Colors
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | Resistive | Mounting Type | Connector |
| Viewing Angle | 12 o'clock | Application | display |
| Interface | RGB | Length | 67.20(H)*105.5(V)*3.0(D)mm |
| Diagonal Screen Size | 4.3inch | Width | 67.20(H)*105.5(V)*3.0(D)mm |
| Drive IC | ST7282 | Screen Size | 4.3inch |
| Driver size | 4.3 Inch tft lcd display module | LCD Type | IPS TFT LCD PANEL |
| Interface Type | RGB 24bit | Resolution | 480*RGB*272 |
| Outline Dimension | 105.5*67.41*4.05mm | Display Area | 95.04*53.86mm |
| Driver IC | ST7282 | Brightness | 500cd/m2 |
| Touch Panel | resistive touch | Color | 262K |
