5.0 Inch LCD Screen PIN40 RGB Interface 500 Contrast Industrial LCD Display Screen
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT display screen | Resolution | 800(Horizontal)*480(Vertical) |
| Display Type | TFT | Backlight Type | LED Display Screen |
| Mounting Type | Connector | Brightness | 250 |
| Display Size | 5.0 inch | Supplier Type | manufacturer |
| Operating Temperature | -20-70 | Screen Size | 5.0 inch |
| Communication Interface | 24bits RGB | Driver Ic | ILI5960+ILI6122 |
| P/N | C050WVI01N | Pixel Pitch | 0.135*0.135 |
| Display Mode | Normally white | Viewing | 12 O'clock |
| Viewing Direction | 70 | Contrast | 500 |
| PIN | 40 | LCM (W x H x D) (mm) | 120.70*75.80*2.80 |
| Active Area(mm) | 108.00*64.80 | Storage Temperature | -30-80 |
