5.2 Inch 240x64 Dots Graphic T6963C 240x64 LCD Display Module 24064 Dot Matrix Display Module
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | Standard | Resolution | 240X64 |
| Display Type | STN, Negative, Blue | Backlight Type | LED Display Screen |
| Display Size | 132.0(H)X39.0(V) mm | Supplier Type | Original manufacture |
| Operating Temperature | -20℃-70℃ | Screen Size | 132.0(H)X39.0(V) mm |
| Communication Interface | 8 bit Parallel | Resolution | 240X64 Dots |
| Outline dimension | 180.0(H)X65.0(V)X14.0(T) mm | Viewing Area | 132.0(H)X39.0(V) mm |
| Active Area | 127.16(H)X33.88X14.0(T) mm | Display mode | STN, Negative, Blue |
| Controller | T6963C | Interface Type | 8 bit Parallel |
| Backlight Type | LED White |
