5.7 Inch LCM 320X240 Graphic Blue LCD Display Module with Resistive Touch Panel
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | STN | Resolution | 320*240 |
| Display Size | 5.7" | Supplier Type | Manufacturer/Factory |
| Communication Interface | 8-bit parallel | Viewing Angle | 6 O'clock |
| Outline Dimensions | 160.0*109.0*12.5mm | View Area | 122.0*92.0mm |
| Active Area | 115.17*86.37mm | Controller IC | RA8835+TSC2046 |
| Display mode | STN/Negative/Transmissive/Blue | Backlight Type | LED White |
| Operating Temp | -20°C~+70°C | Storage Temp | -30°C~+80°C |
| Number of pins | 26 pin |
