7.6 Inch MONO LCD Screen 4098*2560 4K MIPI Interface 7.6" Monochrome LCD Display 50PIN for 3D Printing Device Anycubic Photon M3
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | MONO LCD | Resolution | 4098x2560 |
| Display Type | IPS | Backlight Type | MONO LCD |
| Display Size | 7.6 inch | Supplier Type | Manufacturer |
| Operating Temperature | -20℃~70℃ | Screen Size | 174.96 (W)*113.48(H) |
| Communication Interface | MIPI | Driver Ic | HX8252A00 |
| Dimensional outline | 174.96 (W)*113.48(H) | Active Area | 163.92 (W)*102.4(H) |
| Resolution | 4098*2560 | Interface | MIPI 8 lane |
| Pixel pitch | 0.040*0.040 | Driver IC | HX8252A00*2 |
| Viewing Direction | All | Color | Monochrome |
| Storage Temperature | -30℃~80℃ |
