7 Inch AMOLED Display Module 1080x1920 Capacitive Touch Panel MIPI DSI Interface Industrial Control Screen
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | AMOLED | Communication Interface | MIPI DSI |
| Display Size | 7 inch | Resolution | 1080*1920 |
| Screen Size | 7inch | size | 7.0 inch (Diagonal) |
| Driver Element | AMOLED active matrix | resolution | 1080*1920 |
| Display Mode | amoled | Outline Dimension (mm) | 89.13(W) *160.91 (H) * 1.01 (T) |
| interface | 4 Lanes MIPI DSI | Pixel Pitch(mm) | 0.0403(H)* 0.0806 (V) |
| Display Colors | 1.07 billion colors (RGB*10bits) | Color Arrangement | Rendering |
| Viewing Direction | all |
