7 Inch Display LCD Panel 800*480 HMI Screen RGB TFT Display Module
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT | Resolution | 800X480 |
| Display Type | TFT | Backlight Type | LED Display Screen |
| Mounting Type | Wire Leads | Brightness | 350 |
| Display Size | 7inch | Supplier Type | LCD module |
| Operating Temperature | -20 to 70 | Screen Size | 7inch |
| Communication Interface | TTL | Driver Ic | EK79001 |
| Panel size | 7inch | Resolution | 800*480 |
| dimension | 164.9x100x5.7 | Interface | TTK RGB |
| Brightness | 350 Cd/m2 | input voltage | 3.3V |
| Backlight Type | 27-CHIP WHITE LED | Model Name | MS070QE50SE1 |
| Touch panel | Optional Touch Panel | Panel Type | A- Si TFT Lcd |
