700 Nits High Brightness Ultra Wide 16.4 Inch Android Stretched Bar LCD Display for Supermarket Shelf Edge Advertising
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Application | Indoor | Brightness | 700 cd/㎡ |
| Operating Temperature | 0℃~50℃(0℉~90℉) | Content Management System | Cloud-Based CMS |
| Remote Device Management | Cloud-Based RDM Platform | Input Interface | Micro USB, TF Slot, DC Port |
| Operating System | Android 8.1 | Viewing Angle | 178° |
| Contrast Ratio | 3000 : 1 | Display Coating | AG (Anti-Glare) |
| Refresh Rate | 60 Hz | Response Time | 8 ms |
| Color Gamut | NTSC 100% | Power Consumption | ≤18W |
| Mounting Options | Wall Mounted, Shelf Edge | Backlight Type | WLED |
| Color Temperature | 3000K (Warm White), 5000K (Neutral White), 6500K (Cool White) | Function | IoT Connectivity |
| ROM | 16 G, 32 G, 8G | RAM | 2g |
| Touchscreen Support | / | specification | 13/17 Inch |
| use | Retail, Transportation, Restaurant, Hotel | Motherboard | RK3566 |
| media available | Yes | color | 16.7M (8-bit) |
| lifespan (hours) | 50000 | Connectivity | Support WiFi Connection |
| Reliability | 7 * 24 Hours Continuous Operation | Operating Temp | 0°C ~ 45°C Operating Temp |
| Housing Material | Aluminum Alloy Frame + Metal Case | Dimensions | 432.3 * 93.9 * 17.8 mm |
