8 Inch Wide Temperature LCD Screen GT080S0M-N11 800x600 TFT LCD Display LCD Module
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT |
|---|---|
| Resolution | 800X600, SVGA 125PPI |
| Display Type | TFT |
| Backlight Type | LED Display Screen |
| Mounting Type | Panel Mounting |
| Brightness | 250 cd/m² (Typ.) |
| Display Size | 8 inch |
| Supplier Type | manufacturer |
| Operating Temperature | -20 ~ 70 °C |
| Screen Size | 8.0" |
| Communication Interface | Parallel RGB (1 ch, 6/8-bit) , 50 pins FPC |
| Active Area | 162(W)*121.5(H) mm |
| Outline Dimension | 183(W)*141(H)*5.9(D) mm |
| View angle | 75/75/75/75 (Typ.) |
| Contrast ratio | 500:1 |
| Backlight | 4S5P WLED , Without Driver |
| Display mode | TN, Normally White, Transmissive |
| Response time | 20ms |
| Total Consumption | 1.6W |
| Display Colors | 262K/16.7M 50% NTSC |
