B156ZAN03.0 15.6Inch 3840*2160 UHD 400Nits 60Hz 40Pins EDP 16:9 PCBA Flat Laptop LCD Screen Panel Display Replacement
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| panel type | TFT | products status | New |
| use | For Business | aspect ratio | 16:9 |
| refresh rate | 60 Hz | response time | 30 ms |
| interface type | EDP | brightness | 400cd/m |
| contrast ratio | 1200:1 | vertical viewing angle | 85° |
| warranty(year) | 1-Year | backlit type | LED |
| wide color gamut | 72% NTSC | horizontal viewing angle | 85° |
| color | Black | screen type | LCD |
| built-in speaker | No | series | For Business |
| private mold | No | application | LAPTOP |
| widescreen | Yes | display ratio | 16:9 |
| after-sales service | Return and Replacement | Diagonal Size | 15.6" |
| Panel Type | LTPS TFT-LCD, LCM | Resolution | 3840(RGB)*2160, UHD 283PPI |
| Outline Dim. | 348.22(W)*215.21(H)*2.6(D) mm | Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Support Color | 16.7M 72% NTSC | Light Source | WLED , 15K hours , With LED Driver |
| Form Style | Slim (PCBA Flat, T≤3.2mm) | Interface Type | eDP (4 Lanes) , eDP1.4a , HBR2 (5.4G/lane) , 40 pins Connector |
| Touch Panel | Without |
