CH12232B-2 122x32 COB Chinese Character LCD Screen Module 12232 Dot Matrix Display Serial Port Factory Direct Graphic LCD Module
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | Cob | Resolution | 122x32 |
| Display Size | 60.5x18.0mm(2.38x0.71in) | Supplier Type | manufacturer |
| Operating Temperature | -20℃~+70℃ | Screen Size | 60.5x18.0mm(2.38x0.71in) |
| Driver Ic | st7920 | Outline Dimension | 76.6x28.1x13.0mm |
| Active Area | 54.86x14.36mm | Driver IC | st7920 |
| Interface Type | 8-bit parallel port | Storage Temperature | -30℃~+80℃ |
| Display Color | Blue and white screen/grey and white screen/yellow and green screen | Product Name | CH12232B-2 |
| Connector | pin header interface |
