CH12864-8-3-L 2.6-inch COG LCD Display 128x64 ST7567 Driver IC with Parallel Serial Port LCD Module
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | COG | Resolution | 128X64 |
| Display Size | 66.0x37.65mm(2.60x1.48in) | Supplier Type | manufacturer |
| Operating Temperature | -20℃~+70℃ | Screen Size | 66.0x37.65mm(2.60x1.48in) |
| Driver Ic | ST7567 | Outline Dimension | 71.0x48.0x5.2mm |
| Active Area | 60.78x32.94mm | Resolution | 128*64 |
| Driver IC | ST7567 | Interface Type | Parallel or serial interface |
| Storage Temperature | -30℃~+80℃ | Display Color | Blue and white screen/gray and white screen/yellow and green screen |
| Product Name | CH12864-8-3-L | Connector | FPC plug-in Pitch: 0.5mm |
