COG Type SPI Interface 128x32 Dots Matrix LCD Display FSTN Graphic Monochrome LCD Screen for POS Machine
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | COG | Display Size | 1.7 inch |
| Supplier Type | LCD manufacturer | Item | FSTN Positive Reflective |
| Drive Method | 1/33 DUTY, 1/6 BAIS | Resolution | 128*32 dot matrix |
| Interface | SPI | Module size | 47.85*21*2.8 mm |
| Product Name | 128x32 Monochrome LCD | Application | OBU POS Machine |
| Viewing Angle | 12 O'clock | Drive IC | ST7567 |
| Operating Voltage | 6.5V |
