Customizable 10.4" 4:3 Industrial LCD Monitor HD Monitor 10.4 Inch LED Display Monitoring Room Monitor with VGA/BNC Inputs
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| panel type | IPS | products status | New |
| use | Industrial | aspect ratio | 4:3 |
| refresh rate | 60 Hz | response time | 3 ms |
| interface type | HD/BNC/VGA/Audio | brightness | 450cd/m |
| contrast ratio | 1000:1 | vertical viewing angle | 85° |
| feature | NO Touch | warranty(year) | 1-Year |
| backlit type | LED | horizontal viewing angle | 85° |
| color | Black | screen type | LCD |
| built-in speaker | No | series | For Business |
| private mold | Yes | pixel pitch | 0.242mm(0.01in) |
| application | Desktop | widescreen | No |
| display ratio | 4:3 | after-sales service | Call Center and on-line Technical Support |
| Size/Proportion | 10.4 inch 4:3 | Visible angle | 85/85/85/85 |
| Power input | DC12V | Functional interface | HD,BNC,VGA,Audio |
| Operating temperature/humidity | -10℃ to +60℃/ 0-80% | Storage temperature/humidity | -15℃ to +65℃/ 0-90% |
| OEM/ODM | YES |
