DFSTN Negative 2.4 Inch Small Size 12864 COG FPC 12 Pins Monochrome LCD Display
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | COG | Resolution | 128*64 |
| Display Type | - | Backlight Type | LED Display Screen |
| Mounting Type | - | Brightness | 300 |
| Display Size | 2.4inch | Supplier Type | Manufacturer |
| Operating Temperature | -20~70 ℃ | Screen Size | 53.6 x 29.0mm(2.11x1.14in) |
| Communication Interface | - | Driver Ic | st7567 |
| Name | Graphic LCD Moduel | Dimension | 58.8 x 38.5 x 4.4mm |
| View area | 53.6 x 29.0mm | Display mode | DFSTN, Negative |
| Controller | ST7567 | Viewing Angle | 12 O'clock |
| Driving Voltage | 3v | Backlight | White LED |
