Factory Price 12864 COG Graphic LCD Module 128x64 FSTN Positive 3V Low Energy White LED Backlight ST7567 30 Pin
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | COG | Resolution | 128*64 |
| Display Type | LCD | Backlight Type | LED Display Screen |
| Mounting Type | other | Display Size | 56.4*37.0*6.0 mm(2.22*1.46*0.24in) |
| Supplier Type | OEM | Operating Temperature | -10℃~+60℃ |
| Screen Size | 56.4*37.0*6.0 mm(2.22*1.46*0.24in) | Communication Interface | 30PIN |
| Driver Ic | ST7567 | Type | COG graphic lcd display |
| Display Size | Standard or Custom Size | DIsplay Mode | FSTN positive |
| Drive Method | 1/65 Duty 1/9 Bias | Operating Voltage | 3V |
| Viewing Angle | 06:00 | Backlight | White Leds Backlight |
| Controller IC | ST7567(COG) | Module Size | 56.4(W)x37.0(H)x6.0(T) mm |
