FSTN 128x64 COG 28 Pins 12864 Mono Graphic LCD Module
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | 28 pins 128x64 COG LCD Display | Display Size | 128x64 |
| Supplier Type | Manufacturer | LCD Type | 128x64 COG LCD |
| Model name | TSG12864-1186-FFDLWS-R | Interface | MCU / SPI interface |
| Display type | FSTN, positive, transflective | Outline Dimension | 77.4x52.4x6.5mm |
| Active Area | 66.52x33.24mm | Viewing Angle | 6 O'clock |
| Driver IC | ST7565R | Operatiing Temperature | -20 to 70℃ |
| Storage Temperature | -30 to 80℃ |
