FSTN Positive LCD Display Module ST7565R Interface Transflective Polarizer 12 O'clock View 3.3V COG Pin 50x25 1/65 Duty 1/9 Bias
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | STN | Display Size | 50*25 |
| IC | ST7565R | DISPLAY TYPE | FSTN/POSITIVE |
| POLARIZER | TRANSFLECTIVE | VIEWING DIRECTION | 12:00-CLOCK |
| DRIVE METHOD | 1/65DUTY,1/9BIAS | LCM OPERATING VOLTAGE | 3.3v |
| OPERATING TEMP | 0 TO 50 Deg. C | STORAGE TEMP | -10 TO 60 Deg.C |
| CONNECTOR | COG+PIN | UNSIGNED TOLERANCE | ±0. 20 |
