Graphic LCD Display 240X160 Dot Matrix 24 Pin FPC 8 Bit Parallel 3.3V LCD Display Module 240160 White LED Backlight Fog LCD
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | Graphic | Display Size | 71.80(H)X49.25(V) mm |
| Resolution | 240X160 Dots | Outline dimension | 79.7(H)X63.5(V)X6.4(T) mm |
| Viewing Area | 71.80(H)X49.25(V) mm | AA Area | 62.62(H)X43.34(V) mm |
| Dot Size | 0.241(H)X0.251(V) mm | Dot Pitch | 0.261(H)X0.271 mm |
| Display mode | FSTN, Positive, Transflective | Controller IC | T6963C |
| Backlight Type | LED, White color | Interface | 8 bit Parallel |
