High Brightness 5 Inch 800*RGB*480 TFT LCD Display 650cd/m2 All Viewing Angle Module Panel for Digital Display
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | IPS | Resolution | 800X480 |
| Display Type | TFT | Backlight Type | LED Display Screen |
| Mounting Type | assemble | Brightness | 650 |
| Display Size | 5 inch | Supplier Type | original manufacturer |
| Operating Temperature | -20℃~70℃ | Screen Size | 5.0INCH |
| Communication Interface | RGB | Driver Ic | ST7262 |
| Resolution | 800*RGB*480 | Active Area | 108.00(H)*64.80(V) |
| Outline Dimension | 120.70(V)*75.90(H)*3.05(T) | View direction | ALL |
| Brightness | 650cd/m2 | Interface | RGB |
| Storage Temp. | -30℃~80℃ | Operating Temp. | -20℃~70℃ |
| Touch panel | Optional |
